Universal color LCD digital multimeter HT126B + LED flashlight
Are you looking for a reliable, accurate and modern device for measuring electrical parameters? The universal color LCD digital multimeter HT126B from the renowned manufacturer Habotest is a top-notch device that combines advanced technology, robust design and exceptional ease of use. With its compact design, large color display and built-in LED flashlight, this smart multimeter is the perfect choice for both home craftsmen and demanding professionals working in the field or in the workshop.
Why choose the Habotest HT126B smart multimeter?
The Habotest HT126B is not an ordinary meter. It is a smart device that boasts exceptional accuracy and a robust housing that can withstand even the most demanding conditions of use. Thanks to its thickness of only 25.7 mm and low weight of approximately 182 g, it can easily be put in a pocket or the included protective case. Its key advantage is a large, transparent color display that allows immediate and clear reading of data without eye strain, and silicone buttons provide a pleasant and reliable grip while working.
Main advantages and features

Exceptional measurement accuracy: Accurately measures DC and AC voltage, current, resistance, capacitance, frequency and temperature.
Smart Non-Contact Voltage Detection (NCV): Allows safe detection of the presence of voltage without direct contact with conductors.
Innovative LED input indicators: When you change the measurement mode with the arrows, the LED indicator around the corresponding input port lights up green, guiding you to the correct connection of the test leads.
Built-in powerful LED light: An indispensable feature for working in dark spaces, under dashboards or in electrical cabinets.
True RMS: Provides accurate measurements even with non-sinusoidal AC signals.
Safety first: The device complies with EN61010-1 and CAT III 600V safety standards, ensuring worry-free and safe work.
Practical extras: Data Hold function, low battery indicator, automatic power-off function to save energy and blown fuse warning.

Versatile for every challenge
Whether you are checking diodes, measuring continuity of connections (with an audible signal below 50 ꭥ), testing cable activity (Live test) or measuring temperatures in the range of -40°C to 1000°C, the HT126B multimeter will cope with any task. It only requires 4 standard AAA 1.5 V batteries (not included), which are quick and easy to replace. The soft protective case that you receive upon purchase effectively protects the device from dust and mechanical damage during transport.
Technical specifications



Model
HT126B


DC voltage measuring range
600mV/6V/60V/600V


AC voltage measuring range
6V/60V/600V


DC current measuring range
600mA/10A


AC current measurement range
600mA/10A


Resistance measurement range
600ꭥ/6kꭥ/60kꭥ/600kꭥ/6Mꭥ/60Mꭥ


Capacitance measurement range
6nF/60nF/600nF/6µF/60µF/600µF/6mF/60mF


Frequency measurement range
6Hz/60Hz/600Hz/6kHz/60kHz/600kHz/6MHz/10MHz


Filling factor measuring range
1.0~99.0%


Temperature (°C/°F)
-40°C ~ 1000°C / -40°F ~ 1832°F


Diode testing
Yes, 0~3V


NCV (Non-Contact Voltage)
Yes


Live test
Yes


Continuity
Yes, <50ꭥ (beep)


Number of counts (Counts)
6000


Screen
Color LCD (VA)


Data Hold
Yes


True RMS value (True RMS)
Yes


Blown fuse indication function
Yes


Low battery indicator
Yes


Auto power off function
Yes


Input jack port LED indicator
Yes (green illumination of correct inputs)


Screen lighting
Yes


LED Flashlight
Yes


Power supply
4x 1.5 V AAA batteries (not included)


Safety standard
EN61010-1; CAT III 600V


Weight
Approx. 182g


Dimensions
Approx. 146 x 72 x 26 mm



Frequently Asked Questions (FAQ)
1. What does the NCV function on the HT126B multimeter mean?
The NCV (Non-Contact Voltage) function enables non-contact detection of AC voltage. This means you can safely check if voltage is present in a cable, socket or switch without touching the bare wires with the test probes.
2. How do the LED indicators on the inputs help me with my work?
When you select the desired measurement function on the multimeter (e.g. current or resistance measurement), the device's smart system illuminates the corresponding input ports with a green LED. This prevents incorrect connection of test leads, protects the device from damage and increases user safety.
3. Are batteries included in the package?
No, batteries are not included. To operate the Habotest HT126B smart multimeter, you need 4 standard AAA 1.5 V batteries, which can be quickly and easily inserted into the compartment on the back of the device.


Responsible persons:
HABOTEST - INNPRO Robert Błędowski Sp. z o. o., Rudzka 65c, 44-200 Rybnik, Poland, contact@innpro.eu, (+48) 696323914
Distributor for Slovenia: Haloorodje.si, Online Sales, Rok Groznik sp, Podturn 42, 8350 Dolenjske Toplice, info@haloorodje.si, +38669731944, Slovenia
Product origin: China

Instructions for using the product:
• Turn on the multimeter.
• Select the appropriate measurement function (voltage, current, resistance).
• Connect the multimeter to the circuit you want to check.
• The multimeter will display accurate measurements on a color LCD screen.

Useful tips for work:
• Before use, check whether the multimeter is suitable for your needs.
• A multimeter is suitable for measuring electrical parameters such as voltage, current and resistance.
• When using, be careful not to damage the circuit or yourself.
• After use, turn off the multimeter and store it in a dry place.

Warnings:
• CAUTION – incorrect connection of test leads or selection of the wrong function may cause a short circuit, damage to the multimeter or dangerous electric shock.
• Before measuring, always check that the test leads are connected to the correct inputs.
• Never measure voltage if the red cable is connected to the current input.
• Do not exceed the permissible measurement values; the device is listed with a safety category of CAT III 600 V.
• When measuring mains voltage, use appropriate protective equipment and do not touch the metal parts of the measuring tips.
• Before measuring resistance, capacitance or continuity, the circuit must be turned off and de-energized.
• When measuring current, the multimeter must be correctly connected in series with the circuit.
• After measuring current, remove the test lead from the current input to prevent accidental short circuit during the next measurement.
• Do not use damaged test leads or housing.
• When working with dangerous voltages, follow the manufacturer's instructions and local safety regulations.

Same summary

The HT126B universal color LCD digital multimeter is suitable for home users who need accurate, quick and easy checking of basic electrical quantities, such as voltage up to 600 V, resistance and continuity. Its portability and illuminated display make it practical for field use, use in the garage or on the job site, where visibility conditions are not always ideal. For individuals who frequently measure electrical parameters in demanding environments or need more advanced features, its simple design may be a limitation.

Basic safety features and a digital display make it reliable and user-friendly, especially for beginners or anyone who appreciates a clear numerical readout. The trade-off is especially present for more advanced, laboratory measurements, where additional features or a more stable design might be useful.

Recommendation source: Enaa guides and team experience.

User view

Typical users of this multimeter are home craftsmen, hobby electricians, or those who occasionally need a handy tool to check electrical and automotive components. It is most often used for home wiring repairs, troubleshooting appliances, or checking car batteries, where it comes in handy due to its ease of use and good visibility on the color display even in poor lighting conditions.

Users of Habotest multimeters often trust the brand's reliability and accessibility, as they offer a wide range of robust and proven digital measuring tools - you can see this for yourself on the manufacturer's website, Habotest .

Why buy at Enaa

At Enaa, choosing a multimeter is easy, as data on performance and filters is transparent and tailored to consumers, and we only select proven products from renowned brands - so the information is clear and the decision is easier.

Answers to frequently asked questions

What tasks is this multimeter best suited for?

It is best suited for standard voltage, resistance and continuity testing in the household, garage, field or for basic automotive repairs.

Is this model also suitable for beginners?

Yes, the digital display, clear markings and simple operation make the HT126B very suitable for beginners or users who do not have much experience with measuring devices.

How portable and rugged is the HT126B for field use?

Designed as a handheld model, the multimeter is lightweight and easy to carry. It boasts a robust construction and a display backlight function, which is useful in poorly lit areas or in the field.

Can I safely measure higher voltages with this model?

This model allows measurements up to 600 V, which covers most household and basic electrical installations. When measuring, always follow safety recommendations and do not exceed the specified range of the device.

What protection elements are built into this multimeter?

The HT126B includes basic safety protections such as fuses and overload protection, reducing the risk in normal use in a domestic environment.
